CHASSIS:
- 2U Form Factor
PROCESSOR
* Dual 1207-pin Socket F
* Supports up to two Quad-Core / Dual-Core
AMD Opteron™ 2000 Series (Socket F)
processor(s)
* Dual-core Support
* 1 MB Cache
SYSTEM BUS
* 1000MHz HyperTransport
CHIPSET
* nVIDIA MCP55Pro
MEMORY TYPE
* Sixteen 240-pin DIMM sockets
* Supports up to 64 GB DDR2 667 MHz memory
* For Single CPU: Memory must be populated
in CPU1 DIMMs only
* For Dual CPUs: Recommended that memory be
populated equally in adjacent memory banks
* Dual channel memory bus
DIMM SIZES
* 256 MB, 512 MB, 1GB, 2GB, 4GB
MEMORY VOLTAGE
* 1.8V only
SATA
* nVidia MCP55 Pro SATA2 3.0Gbps Controller
* 6 SATA Ports
* nVidia Host RAID 2.0
* SATA RAID 0, 1, 0+1, 5, JBOD Support
IPMI
* Intelligent Platform Management Interface
v.2.0 (Optional: AOC-SIMSO(+) R 3.00)
* RMM (Remote Management Module)
* (Card not included)
* For dedicated LAN, CBL-0177L must be used
(Cable not included)
NETWORK CONTROLLERS
* nVidia MCP55 Pro Chipset Dual-port LAN /
Ethernet Controller
* Supports 10BASE-T, 100BASE-TX, and 1000BASE-T,
RJ45 output
VGA
* ATI ES1000 Graphics Controller
SUPER I/O
* Winbond 83627HF
IDE
* Single EIDE channel support up to two UDMA
IDE devices
* Supports UDMA Mode 5
* Supports PIO Mode 4
* Supports ATA 100/133
FLOPPY
* 1 Floppy port; 1.44 MB support
LAN
* 2 RJ45 LAN ports
USB
* FUCI
* Up to 6 USB Ports 2.0 Compliant
* 2 Rear Ports
* 4 Internal Headers
VGA
* 1 VGA port
KEYBOARD / MOUSE
* PS/2 keyboard and mouse ports
SERIAL PORTS
* 1 Fast UART 16550 serial port
* 1 serial port header
OTHERS
* 1 UID
|
BIOS TYPE:
* 8Mb Flash EEPROM with AMI® BIOS
BIOS FEATURES:
* Plug and Play (PnP)
* SMBIOS 2.3
* DMI 2.3
* PCI 2.2
* ACPI 2.0
* USB Keyboard support
* Hardware BIOS Virus protection
DIMENSIONS:
- Height 3.5" (89mm)
- Width 17.2" (437mm)
- Depth 25.5" (648mm)
- Gross Weight 55 lbs (24.9kg)
- Available Colors Silver, Black
FRONT PANEL BUTTONS:
• Power On/Off button
• System Reset button
FRONT PANEL LEDs:
• Power LED
• Hard drive activity LED
• 2x Network activity LEDs
• System Overheat / Fan Fail LED
• Power fail LED
FRONT PANEL PORTS:
•
2x USB Ports + DB9 COM Port (optional)
PCI-EXPRESS EXPANSION SLOTS:
* 2 (x8) PCI-e slots
* 1 (x4) PCI-e (using x8) slot
PCI-X EXPANSION SLOTS:
* 2x 64-bit 133MHz PCI-X (3.3V) slots
* 1x 64-bit 100MHz PCI-X (3.3V) slot
HOT-SWAP DRIVE BAYS:
* 8x 3.5"SATA Hot-swap drive trays
* Supports up to 6x SATA hard drives
DVD-ROM:
* Slim 8x DVD, 24x CD, DVD-ROM Drive
SATA BACKPLANE:
* 1x 2U SATA backplane
SYSTEM COOLING FANS:
* 3x 80mm 6300 RPM fans
SHROUD:
* 1x Air Shroud
POWER SUPPLY:
*
(1 + 1) Redundant 700W AC-DC power supply w/ PFC
AC Voltage - 100 - 240V, 60-50Hz, 10 - 4 Amp
+5V standby - 4 Amp
+12V - 57 Amp
PC HEALTH MONITORING:
* Monitors for CPU Cores, +3.3V, +5V, ±12V, +1.2V
* 5-Phase-switching voltage regulator with auto-sense from 0.8375V-1.60V
FAN:
* Total of four 3-pin and four 4-pin fan headers supporting up to 8 fans
* 8x fans with tachometer status monitoring
* Status monitor for speed control
* Status monitor for on/off control
* Low noise fan speed control
* Pulse Width Modulated (PWM) fan connectors
TEMPERATURE:
* Monitoring for CPU and chassis environment
* CPU thermal trip support
* Thermal Control for 8x fan connectors
* PSU I2C temperature sensing logic
* Thermal Monitor 2 (TM2) support
LED:
* CPU / System Overheat LED
OTHER FEATURES:
* Chassis intrusion detection
* Chassis intrusion header
* SDDC Support
OPERATING ENVIRONMENT / COMPLIANCE ENVIRONMENTAL SPEC.:
* Operating Temperature: 10º to 35º C (50º to 95º F)
* Non-operating Temperature: -40º to 70º C (-40º to 158º F)
* Operating Relative Humidity: 8% to 90% (non-condensing)
* Non-operating Relative Humidity: 5 to 95% (non-condensing)
|
