CHASSIS:
- Standard 1U Form Factor
POWER SUPPLY:
- 650 Watts
FANS:
- 2x10cm Internal Blower Fans
- Power Supply Fan
CHIPSET:
- Supermicro X7DBR-3 Motherboard
- Intel 5000P Chipset
- 1333MHz Front Side Bus
MEMORY:
- Up to 64GB of 667MHz DDR ECC/Registered Fully Buffered Memory
-16x Fully Buffered DIMM Sockets
PROCESSOR:
- Two Quad Core or Dual Core Xeon Processors with up to 12MB Cache. 5000/5100/5200/5300/5400 Sequence
I/O PORTS:
- Two Serial Ports
- Two PS/2 Connectors (Keyboard and Mouse)
- Two USB 2.0 Ports (Located in Rear)
EXPANSION CAPABILITIES:
- One Universal PCI-X or PCI-E Slot
DRIVE BAYS:
- Four Hot-Swap Removable SATA Drive Bays
- One Slim CD-ROM Drive Bay
- One Floppy Drive Bay
|
STORAGE ARRAY:
- Four 250GB Drives for 1TB Raw Storage or 750GB Actual Redundant Storage
- Four 500GB Drives for 2TB Raw Storage or 1.5TB Actual Redundant Storage
- Four 750GB Drives for 3TB Raw Storage or 2.25TB Actual Redundant Storage
- Four 1TB Drives for 4TB Raw Storage or 3TB Actual Redundant Storage
- RAID Level 5 (Default Configuration)
- Can be Confi gured for RAID 0/1/5/6/10/50
RAID CONTROLLER:
- AMCC 3Ware 9650SE-4LPML 4 Port SATAII RAID Controller
HARD DISKS:
- 7200RPM Serial ATA-II Hard Drives
VIDEO:
- Onboard ATI ES1000 16MB Video Adapter
NETWORK:
- Dual Onboard Intel 10/100/1000 Gigabit Adapters
DIMENSIONS:
- Height: 1.75”
- Width: 19”
- Depth: 25.6”
WEIGHT:
- 45 lbs (Default Configuration)
INCLUDED SOFTWARE AND DOCUMENTATION:
- Linux Install CD Set
- Getting Started Guide
OPERATING SYSTEM:
- CentOS 5 with Current Updates, Security Fixes and Bug Fixes
|
