CHASSIS:
- Standard 3U Form Factor
POWER SUPPLY:
- Standard Redundant Hot-Swappable 800 Watt Power Supply
FANS:
- 3x 80mm Hot-swappable Fans
- 2x 80mm Rear-exhaust Fans
CHIPSET:
- X7DBE Motherboard
- Intel 5000P Chipset
- 1333MHz Front Side Bus
MEMORY:
- Up to 32GB of 667MHz DDR ECC Fully Buffered Memory
- 8x DDR DIMM Sockets
PROCESSOR:
- Dual Quad Core or Dual Core Xeon Processors with up to 12MB Cache. 5000/5100/5200/5300/5400 Sequence
I/O PORTS:
- One Serial Port
- One Parallel Port
- Two PS/2 Connectors (Keyboard and Mouse)
- Two USB 2.0 Ports (Located in Rear)
EXPANSION CAPABILITIES:
- Two PCI-X 133MHz 64-Bit Full Length Slots
- One PCI-X 100MHz 64-Bit Full Length Slot
|
DRIVE BAYS:
- Sixteen Hot-Swap Serial ATA Drive Bays
- One Slim CD-ROM/DVD-ROM Drive Bay
- One Slim Floppy Drive Bay
STORAGE ARRAY:
- Up to Sixteen 750GB SATA Drives or 146GB SAS Drives
- 12TB Raw/11.25TB Available Redundant SATA Storage
- 2.3TB Raw/2.19TB Available Redundant SAS Storage
- RAID Level 5 (Default Confi guration)
- Can be confi gured for RAID 0/1/5/10/50/6
MANAGEMENT:
- Optional PogoRemote IPMI 2.0 for Out of Band Management
RAID CONTROLLER:
- AMCC 3Ware 9650SE-16ML 16 Port SATAII RAID Card
HARD DISKS:
- 7200RPM Serial ATA
VIDEO:
- Onboard ATI ES1000 16MB Video Adapter
NETWORK:
- Dual Onboard nVidia 10/100/1000 Ethernet
- Optional Qlogic FC Controller
DIMENSIONS:
- Height: 5.25”
- Width: 17”
- Depth: 26.5”
WEIGHT:
- 78 lbs (Default Configuration)
INCLUDED SOFTWARE AND DOCUMENTATION:
- Linux Installation CD Set
- Getting Started Guide
|
