CHASSIS:
- Compact 3U Form Factor
POWER SUPPLY:
- Redundant Hot-Swap 850 Watts
FANS:
- Twelve Hot-Swap Case Fans
CHIPSET:
- AMD-8111 Chipset
MEMORY:
- Up to 64GB of PC2700 DDR ECC Registered Memory
- 16x DDR DIMM Sockets
- Supports PC3200 DDR ECC Registered Memory
PROCESSOR:
- Support for 4-way 800 Series AMD Opteron Processors
- AMD Opteron 848 2.2 GHz w/1MB Cache
- AMD Opteron 850 2.4 GHz w/1MB Cache
- AMD Opteron 852 2.6 GHz w/1MB Cache
- AMD Opteron 854 2.8 GHz w/1MB Cache
- AMD Opteron 865 1.8 GHz Dual Core
- AMD Opteron 870 2.0 GHz Dual Core
- AMD Opteron 875 2.2 GHz Dual Core
- AMD Opteron 880 2.4 GHz Dual Core
I/O PORTS:
- One Serial Port, One Parallel Port
- Two PS/2 Connectors (Keyboard and Mouse)
- Two USB Ports (One Front and One Rear)
EXPANSION CAPABILITIES:
- Four 64-Bit 133MHz Full Length Hot-swap PCI-X Expansion Slots
- Two 64-Bit 100MHz Full Length PCI-X Expansion Slots
- One 64-Bit 66MHz Half-Port PCI-X Expansion Slot
|
DRIVE BAYS:
- Five Hot-Swap Ultra-320 SCSI Hard Drive Bays with Optional RAID
- One Slim DVD-ROM Drive Bay
- One Slim Floppy Drive Bay
HARD DISKS:
- Seagate 36GB U-320 10k RPM 80-Pin SCSI Hard Drive
- Seagate 36GB U-320 15k RPM 80-Pin SCSI Hard Drive
- Seagate 73GB U-320 10k RPM 80-Pin SCSI Hard Drive
- Seagate 73GB U-320 15k RPM 80-Pin SCSI Hard Drive
- Seagate 146GB U-320 10k RPM 80-Pin SCSI Hard Drive
- Fujitsu 300GB U-320 10k RPM 80-Pin SCSI Hard Drive
VIDEO:
- Onboard ATI Rage-XL 8MB Video Adapter
NETWORK:
- Dual Onboard Gigabit Ethernet Ports
MANAGEMENT:
- Integrated Service Processor with IPMI 2.0 Management
DIMENSIONS:
- Height: 5.2”
- Width: 17.5”
- Depth: 28.5”
WEIGHT:
- 75 lbs. (Default Confi guration)
INCLUDED SOFTWARE AND DOCUMENTATION:
- Linux CD Set
- Server Quick Start Guide
|
