CHASSIS:
- 5U Form Factor
POWER SUPPLY:
- Redundant Hot-Swap 1350 Watts
FANS:
- Two Hot-Swap 120x120 4k RPM Fans
- Two Easy-Swap 120x120 4k RPM Fans
- One Easy-Swap 60x60 6k RPM Fan
CHIPSET:
- nVidia nForce Professional 2200
- nVidia nForce Professional 2050
- AMD 8131 PCI-X Tunnel Chip
MEMORY:
- Up to 128GB of DDR-400 ECC/Registered Memory
- 32x 184-Pin DDR DIMM Sockets
PROCESSOR:
- Supports up to 8x AMD Opteron Socket 940 Single & Dual Core Processors
- AMD Opteron 848 2.2 GHz w/1MB Cache
- AMD Opteron 850 2.4 GHz w/1MB Cache
- AMD Opteron 852 2.6 GHz w/1MB Cache
- AMD Opteron 854 2.8 GHz w/1MB Cache
- AMD Opteron 865 1.8 GHz Dual Core w/1MB Cache
- AMD Opteron 870 2.0 GHz Dual Core w/1MB Cache
- AMD Opteron 875 2.2 GHz Dual Core w/1MB Cache
- AMD Opteron 880 2.4 GHz Dual Core w/1MB Cache
- AMD Opteron 885 2.6 GHz Dual Core w/1MB Cache
I/O PORTS:
- Two Serial Ports
- Two PS/2 Connectors (Keyboard and Mouse)
- Two USB 2.0 Ports
- One External SAS Port
|
EXPANSION CAPABILITIES:
- Two PCI-Express x16 Slots
- One PCI-Express x4 Expansion Slot
- Five PCI-X 64-Bit 133MHz Expansion Slots
DRIVE BAYS:
- Six Hot-Swap SCSI Hard Drive Bays
- One Slim 8x DVD-ROM Drive
HARD DISKS:
- 36GB U320 10k RPM SCSI Hard Drive
- 36GB U320 15k RPM SCSI Hard Drive
- 73GB U320 10k RPM SCSI Hard Drive
- 73GB U320 15k RPM SCSI Hard Drive
- 146GB U320 10k RPM SCSI Hard Drive
- 300GB U320 10k RPM SCSI Hard Drive
VIDEO:
- Onboard ATI Rage 7000M 8MB Video Adapter
NETWORK:
- Onboard Dual Broadcom PCI-E X1 Gigabit Adapters
DIMENSIONS:
- Height: 8.7”
- Width: 17.6”
- Depth: 33.6”
WEIGHT:
- 150 lbs. (Default Confi guration)
INCLUDED SOFTWARE AND DOCUMENTATION:
- Linux CD Set
- Getting Started Guide
|
