CHASSIS:
- Standard 2U Form Factor
POWER SUPPLY:
- Redundant Hot-Swappable 500 Watts
FANS:
- Four Internal Blower Fans
- Power Supply Fans
CHIPSET:
- Supermicro X7DBE Motherboard
- Intel 5000P Chipset
- 1333MHz Front Side Bus
MEMORY:
- Up to 16GB of DDR2 Fully Buffered ECC Registered Memory
- 8x Fully Buffered DDR2 DIMM Sockets
PROCESSOR:
- Support for Two Intel Quad or Dual Core Xeon Processors 5000/5100/5200/5300/5400 Sequence
I/O PORTS:
- One Serial Port
- One Parallel Port
- Two PS/2 Connectors (Keyboard and Mouse)
- Two USB 2.0 Ports (Located in Rear)
EXPANSION CAPABILITIES:
- Two 66MHz 64-Bit Full Length PCI Slot (One Used by the 3Ware RAID Card)
|
DRIVE BAYS:
- Twelve Hot-Swap Removable Serial ATA Drive Bays
STORAGE ARRAY:
- Twelve 250GB Drives for 3TB Raw Storage or 2.75TB Actual Redundant Storage
- Twelve 500GB Drives for 6TB Raw Storage or 5.5TB Actual Redundant Storage
- Twelve 750GB Drives for 9TB Raw Storage or 8.25TB Actual Redundant Storage
- Twelve 1TB Drives for 12TB Raw Storage or 11TB Actual Redundant Storage
- RAID Level 5 (Default Confi guration)
- Can Be Confi gured for RAID 0/1/5/6/10/50
RAID CONTROLLER
- AMCC 3Ware 9590SE-12ML 12 Port SATA Controller with 256MB Cache (Optional
Battery Backup Available)
VIDEO:
- Onboard ATI ES1000 16MB Video Adapter
NETWORK:
- Dual Onboard 10/100/1000 Gigabit Ethernet Ports
DIMENSIONS:
- Height: 3.5”
- Width: 19”
- Depth: 27.5”
WEIGHT:
- 65 lbs (Default Confi guration)
INCLUDED SOFTWARE AND DOCUMENTATION:
- Getting Started Guide
|
