Atlas 114-12

  • Add to Cart

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

  • View Specs

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

Generate PDF review my config

$6,410.12

  • AMD EPYC 9004 Series Processor
  • Up to 3072GB of DDR5 ECC Reg Memory
  • 12x 2.5" Hot-swap NVMe SSD Bays
  • 2x 10GBe Onboard
  • 5x Expansion Slots
  • 850W Platinum Redundant Power Supplies
Atlas 114-12
Processor and Memory
CPU
Memory
OS Drives
OS Drives
Hard Disk Drives
Drives 1-4 SATA/SAS/NVMe
Drives 5-12 NVMe
Optional OCP Networking
PCI Express Expansion Cards
PCIe Slot 1
PCIe Slot 2
Operating Systems
Operating System
RAID Configuration
RAID Level
Support Options
Warranty and Support

Atlas 114-12

Atlas 114-12
Processor Support
CPU
AMD EPYC 9004 Series Processor
Socket
AMD Socket SP5
Memory
Dimm Slots
(24) DIMM slots
Type
RDDR5 4800 w/ ECC
Capacity
Up to 3,072GB RDIMM/3DS RDIMM DDR5
OnBoard Devices
SATA
(1) SFF-TA-1016 (MCIO 8x) for (4) SATA ports
NVME
(6) SFF-TA-1016 (MCIO 8x) for (12) front NVMe
IPMI
Aspeed AST2600
Network Controller
Intel X710-AT2
Input/Output
LAN
(2) 10GbE ports
IPMI
(1) GbE dedicated for IPMI
USB
(1) USB3.2 Gen.1 conn. (Type-A) / (1) USB3.2 Gen.1 header / (1) USB3.2 Gen.1 port (@ front) / (2) USB3.2 Gen.1 ports (@ rear)
VGA
(1) D-Sub 15-pin port
Serial Port
(1) DB-9 COM port
Chassis
Form Factor
1U
Depth
26.77"
Height
1.69"
Width
17.26"
Average Weight
60Lbs
Expansion
PCI-E 1
(1) M7136G68-L16-1F (1) FH/HL PCIe Gen.5 x16 slot (Left)
PCI-E 2
(1) M7136G68-R16-1F for (1) FH/HL PCIe Gen.5 x16 slot (Right)
Drive Bays
Hot Swap
12x U.2
OS
2x M.2
System Cooling
Fan 1
(3) 4028 fans
Fan 2
(3) 4056 fans
Power
Spec
850 Watts 80 plus Platinum Redundancy 1+1
Input
AC 100~240V/12~6A
