Intrepid 223-12

  • Add to Cart

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

  • View Specs

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

Generate PDF review my config

$5,166.67

  • Dual 4th Generation Intel Xeon Scalable Processors
  • Up to 4TB DDR5 ECC Registered Memory
  • Several Networking options
  • 12x 3.5" NVMe/SATA Drive Bays
  • Robust web-based remote management
  • Platinum Level Power Supplies
  • 5 PCIe 5.0 Slots
Intrepid 223-12
Processor and Memory
CPUs
Memory
OS Drives
Rear OS SATA Drives 1-2
SSD Drives
SATA/NVMe Drives 1-4
SATA/NVMe Drives 5-8
SATA/NVMe Drives 9-12
Optional OCP Networking
Optional OCP Networking Slot 1
Optional OCP Networking Slot 2
PCIe Expansion
PCIe 5.0 x16 FHFL Slot 1
PCIe 5.0 x16 FHFL Slot 2
PCIe 5.0 x16 FHFL Slot 3
PCIe 5.0 x16 FHFL Slot 4
PCIe 5.0 x16 FHFL Slot 5
Pre-Installed Operating System
Operating System
VROC
Intel® Virtual RAID on CPU (Intel® VROC)

Intel VROC - Premium NVMe Raid Hardware Key   $250.00

RAID Configuration
RAID Level
Support Options
Warranty and Support

Intrepid 223-12

Intrepid 223-12
Processor Support
CPU
4th Generation Intel® Xeon® Scalable Processors
Socket
2x LGA 4677
Memory
Dimm Slots
32
Type
DDR5 4800MT/s ECC Reg
Capacity
2TB
OnBoard Devices
Chipset
Intel C741 Chipset
IPMI
Aspeed AST2600
Network Controller
I350-AM2
Input/Output
LAN
2x 1Gbe RJ45 port
IPMI
1x RJ-45 Management LAN port
USB
Front: 2 x USB 3.2 Gen1 ports Rear: 2 x USB 3.2 Gen1 ports
VGA
1x Mini-DP
Chassis
Form Factor
2U
Depth
1077mm
Height
300mm
Width
679mm
Expansion
PCI-E 1
5x FHHL PCIe Gen5 x16 slots
OCP 3.0 Gen5 x16 mezzanine slots
x2
Drive Bays
Hot Swap
12x 3.5/2.5" Gen4 NVMe/SATA hot-swappable bays
OS
2x 2.5" SATA hot-swappable bays on rear side
Power
Spec
Dual 2000W (240V) 80 PLUS Platinum redundant power supply
Input
100-120V~/ 12A, 50-60Hz; 180-240V~/ 10A, 50-60Hz
