Intrepid 223-24-N

  • Add to Cart

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

  • View Specs

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

Generate PDF review my config

$5,633.33

  • Dual 4th Generation Intel Xeon Scalable Processors
  • Up to 4TB DDR5 ECC Registered Memory
  • Several Networking options
  • 12x 2.5" NVMe Drive Bays
  • 12x 2.5" NVMe/SATA Drive Bays
  • Robust web-based remote management
  • Platinum Level Power Supplies
  • 4 PCIe 5.0 Slots
Intrepid 223-24-N
Processor and Memory
CPUs
Memory
OS SATA SSD Drives
SATA SSDs 1-2
Additional SATA SSD Drives
Additional SATA SSDs 1-2
SSD Drives
NVMe U.2 SSDs 1-6
NVMe U.2 SSDs 7-12
NVMe/SATA SSDs 13-18
NVMe/SATA SSDs 19-24
PCIe Expansion
PCIe 5.0 x16 FHFL Slot 1
PCIe 5.0 x16 FHFL Slot 2
PCIe 5.0 x16 FHFL Slot 3
PCIe 5.0 x16 FHFL Slot 4
Pre-Installed Operating System
Operating System
VROC
Intel® Virtual RAID on CPU (Intel® VROC)

Intel VROC - Premium NVMe Raid Hardware Key   $250.00

RAID Configuration
RAID Level
Support Options
Warranty and Support

Intrepid 223-24-N

Intrepid 223-24-N
Processor Support
CPU
4th Generation Intel® Xeon® Scalable Processors
Socket
2x LGA 4677
Memory
Dimm Slots
32
Type
DDR5 4800MT/s ECC Reg
Capacity
2TB
OnBoard Devices
Chipset
Intel C741 Chipset
IPMI
Aspeed AST2600
Network Controller
I350-AM2
Input/Output
LAN
2x 1Gbe RJ45 port
IPMI
1x RJ-45 Management LAN port
USB
Front: 2 x USB 3.2 Gen1 ports Rear: 2 x USB 3.2 Gen1 ports
VGA
1x Mini-DP
Chassis
Form Factor
2U
Depth
1077mm
Height
300mm
Width
679mm
Expansion
PCI-E 1
4x FHHL PCIe Gen5 x16 slots
Power
Spec
Dual 2000W (240V) 80 PLUS Platinum redundant power supply
Input
100-120V~/ 12A, 50-60Hz; 180-240V~/ 10A, 50-60Hz
Drive Bays
2.5" Gen4 NVMe/SATA hot-swappable bays
12x
2.5" Gen4 NVMe hot-swappable bays
12x
