Storage Director Flex HA

  • Add to Cart

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

  • View Specs

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

Generate PDF review my config

Call/Email

  • QuantaStor Standard or Enterprise Edition
  • Custom QuantaStor Licensing Available
  • Highly available head node in a box for JBOD and JBOF Control
  • Independent power control - Each node has its own power front-panel
  • 2 Nodes provide for High Availability
  • Provides for easy cabling, better airflow and reduced cabling costs
  • 1600W 80 PLUS Platinum High-efficiency Redundant Power Supplies
Storage Director Flex HA
Processor and Memory
CPU
Memory
Storage
M.2 SSD (2 Per Node)
U.2 SSD (2 Drives Per Node)
Networking Options
Onboard Networking

1x 10G Base-T RJ45

HBA
Broadcom HBA 9500-16e Tri-Mode Storage Adapter - Node 1

Broadcom HBA 9500-16e Tri-Mode Storage Adapter

Broadcom HBA 9500-16e Tri-Mode Storage Adapter - Node 2

Broadcom HBA 9500-16e Tri-Mode Storage Adapter

PCIe Expansion
PCIe Expansion Node 1 - Slots 1-3
PCIe Expansion Node 2 - Slots 1-3
QuantaStor Standard or Enterprise Edition
QuantaStor - Software Defined Composable Storage

More Info

One year Free VSA for Microsoft Azure
VSA for Microsoft Azure
Warranty and Support Options
Warranty and Support

Storage Director Flex HA

Storage Director Flex HA
Processor Support
CPU
3rd Generation Intel Xeon Scalable Processor
Socket
Dual Intel Socket (FCLGA4189) Per Node
Memory
Dimm Slots
16 Per Node
Type
DDR4 3200MHz ECC Registered DDR4, 3200MHz, ECC REG (Per Node)
Capacity
2048GB Per Node
OnBoard Devices
Chipset
Intel C621A Chipset
NVME
2x M.2 Sockets Per Node
IPMI
Dedicated Management controller IPMI 2.0 Compliant
Input/Output
LAN
1 RJ45 10GBASE-T Ethernet Port Per Node
IPMI
1 RJ45 IPMI Port Per Node
USB
1 X USB 3.0 Port, 2 X USB 3.0 via Breakout Cable Per Node
VGA
1 X VGA via Breakout Cable Per Node
Serial Port
1 X Serial Port via Breakout Cable Per Node
Power
Spec
2100W Power Supply
